Specifications
Frequency range from 1MHz to 3GHz
Range of Z from 1 to 1000 ohm
RF Generator power output of -6dBm @ 500 MHz
Dynamic range of up to 70 dB @ 500 MHz
Supply is Powered from USB Features
SMA connectors for better isolation
Calibration using open-short-load for accurate results
Two port VNA with S11 and S21; displayed and save results
Export data in several formats JPEG, EXCEL, ZPLOT, S2P, PDF
Boot loader for future firmware upgrades
User friendly interface for PC Windows Linux and Mac
Integrated Smith chart in software
Android Mobile Phone software free Manuals
Manual miniVNA Tiny Hardware
Software for miniVNA by DL2SBA
